Learning Objectives
- Know the differences between alignment and read mapping.
- Know how to perform read mapping.
- Know how to predict read coverage.
- Get an graphical impression of mapping.
Mapping or alignment is the process of taking often short fragments of genetic data (nucleotide or protein) and matching them to their locations on a known reference sequence.
Mapping or alignment
Although the terms alignment and mapping are often used interchangeably, they actually refer to two distinct methods. We map raw reads, but we align or cluster curated sequences with fewer or no sequencing errors.
Challenges
Multiple sequence alignments (MSA)
In our first challenge we will perform a multiple sequence alignment of different SARS-CoV-2 strains.
There are many tools available to align multiple fasta sequences. We are going to use a webtool as there are only few sequences and the genome of the virus is pretty small. Download the fasta file using this link here.
Challenge 1: How many strains do we have?
We are going to use mafft which runs at EMBL. Just use all default settings and upload the fasta file.
Challenge 2: Have a look at the alignment. What is the difference between an alignment and a fasta file?
Suggestion
All sequences are forced to be the exact same length. This is achieved by inserting gaps (usually represented by dashes -) to represent insertions or deletions (indels).
Challenge 3: Have a look at the Neighbour-joining tree? What do you think about the topology?
Suggestion
As we are not virologists, it would be useful to have more biological replicates, as these would help us to understand biological patterns. The methods are not extremely sophisticated, and there are regions within the genome that would be better for studying the evolution of these strains.
Coverage Calculation
The required sequencing depth depends on the application and your research questions. Effective coverage is often lower than theoretical coverage due to repeats in the genome, PCR duplicates or alignment artefacts.
Challenge 4: Theoretical coverage
We are going to generate SNPs data in a non-model species using Illumina short reads. Use the coverage calculator and find out how many samples you can run in one lane of a 1.5 Tb NovaSeq X flow-cell.
Platform: NovaSeq X 1.5 Tb flow-cell, 1 lane.
Protocol: PE 2X150 bp
Genome size (2n): 0.600 Gb
Suggestion
I normally use this html script CovCalculator.
The haploid genome size is 0.3 Gbp. I normally target 12 x coverage for SNP calling if you have multiple samples per populations including a data loss of 25–30%. This means that approximately 46 samples can be sequenced per lane, or 92 samples per 1.5 Tb flow cell.
Read mapping
For our next challenge we going to use a reduced data set containing different strains of the parasite Crithidia bombi infecting bumblebees. Find more information here.
We have 4 samples ERR3418932, ERR341896, ERR3418937 and ERR3418936 from different strains. To speed up the analysis we are going to use only 1 scaffold of the Crithidia bombi genome. Find more information about the genome here.
Login to our server.
ssh guest?@gdc-vserver.ethz.ch
Let's download the data and open the tar file.
cd ${HOME}
mkdir mapping
cd mapping
curl -O https://www.gdc-docs.ethz.ch/GeneticDiversityAnalysis/GDA/data/mapping.tar.gz
tar xvzf mapping.tar.gz && rm mapping.tar.gz
In your folder you will find the following files.
raw reads (e.g. ERR3418932_1.fq.gz and ERR3418932_2.fq.gz)
reference genome (Ref_C_bombi.fasta)
annotation e.g. where genes are located (Ref_C_bombi.gff)
First, we need to index the reference.
bwa-mem2 index Ref_C_bombi.fasta
Challenge 5: Why we need to index the reference?
Suggestion
Indexing the reference genome massively improves speed and efficiency, making read mapping feasible for large-scale sequencing data.
In order to make our code easier to read (e.g. more reproducible) we define variables.
SAMPLE=ERR3418937
REF=Ref_C_bombi.fasta
We map reads to the reference using the default settings of bwa-mem2 and add a read group and output a sam file.
bwa-mem2 mem -R "@RG\tID:${SAMPLE}\tSM:${SAMPLE}\tPL:Illumina" ${REF} ${SAMPLE}_1.fq.gz ${SAMPLE}_2.fq.gz > ${SAMPLE}.sam
Challenge 6: Why we should never keep sam files? And what is a read group?
Suggestion
We compress sam to bam files to reduced disk space.
A read group corresponds in many cases to the sample names.
Now, let's sort the sam file and compress it.
samtools sort ${SAMPLE}.sam -o ${SAMPLE}_sort.bam
Challenge 7: Check out the mapping statistics. How many reads could you map?
samtools flagstat ${SAMPLE}_sort.bam
flagstats output
| Flagstats | Information |
|---|---|
| total | All reads |
| mapped | All mapped reads |
| paired in sequencing | R1 and R2 could be mapped |
| properly paired | R1 and R2 could be mapped within insert range |
| with itself and mate mapped | R1 and R2 could be mapped also outside insert range |
| singletons | Either R1 or R2 could be mapped |
| mate mapped to a different chr | R1 or R2 could be mapped on different chromosomes |
Now, we remove reads with mapping quality lower than 20 to get rid of ambiguous alignments.
samtools view -bh -q 20 -F 0x800 -F 0x100 ${SAMPLE}_sort.bam > ${SAMPLE}_sort_Q20.bam
Challenge 8: What does the flags 0x800 and 0x100 mean? Use the Sam flag decoder.
Suggestion
We remove supplementary and not primary alignment, which are low quality hits. The numbers here are presented as hexadecimal numbers. Q20 as decimal number.
To account possible PCR duplicates we remove them and index the final bam file.
samtools collate -O -u ${SAMPLE}_sort_Q20.bam | samtools fixmate -m -u - - | samtools sort -u - | samtools markdup -r -f dup_${SAMPLE} - ${SAMPLE}_sort_Q20_fix_nodup.bam
samtools index ${SAMPLE}_sort_Q20_fix_nodup.bam
Challenge 9: Check again the mapping statistics to find out how many reads could have been mapped? What is the mapping rate?
Let's calculate the mean coverage.
samtools coverage ${SAMPLE}_sort_Q20_fix_nodup.bam
If you like to have a more detailed report you can use qualimap.
qualimap bamqc -bam ${SAMPLE}_sort_Q20_fix_nodup.bam
Challenge 10: Transfer the qualimap folder to your local computer and open the HTML file in your browser. How meaningful are mean values in this context?
Suggestion
The variation across the genome is rather high, so the absolute values are inflated. When comparing samples, it's easier to have only one value.
To keep our folder tidy, let's delete the intermediate files.
rm ${SAMPLE}.sam ${SAMPLE}_sort.bam* ${SAMPLE}_sort_Q20.bam*
As we have now 3 more samples to map we are going to use bash loop to process all the samples in one command.
First, we generate a sample list and remove the endings.
ls *_1.fq.gz | sed 's/_1.fq.gz//' > sample.lst
Then we use a loop to map all the samples in sample.lst
#!/bin/bash
##define variable
REF=Ref_C_bombi.fasta
##bash loop to map reads against the genome
for SAMPLE in $(cat sample.lst)
do
bwa-mem2 mem -R "@RG\tID:${SAMPLE}\tSM:${SAMPLE}\tPL:Illumina" ${REF} ${SAMPLE}_1.fq.gz ${SAMPLE}_2.fq.gz > ${SAMPLE}.sam
samtools sort ${SAMPLE}.sam -o ${SAMPLE}_sort.bam
samtools flagstat ${SAMPLE}_sort.bam > ${SAMPLE}_sort.stats
samtools view -hb -q 20 -F 0x800 -F 0x100 ${SAMPLE}_sort.bam > ${SAMPLE}_sort_Q20.bam
samtools index ${SAMPLE}_sort_Q20.bam
samtools collate -O -u ${SAMPLE}_sort_Q20.bam \
| samtools fixmate -m -u - - \
| samtools sort -u - \
| samtools markdup -r -f dup_${SAMPLE} - ${SAMPLE}_sort_Q20_fix_nodup.bam
samtools index ${SAMPLE}_sort_Q20_fix_nodup.bam
samtools flagstat ${SAMPLE}_sort_Q20_fix_nodup.bam > ${SAMPLE}_sort_Q20_fix_nodup.stats
samtools coverage ${SAMPLE}_sort_Q20_fix_nodup.bam > ${SAMPLE}_sort_Q20_fix_nodup.cov
rm ${SAMPLE}.sam ${SAMPLE}_sort.bam* ${SAMPLE}_sort_Q20.bam*
done
Let's copy the script above in a text file and call it mapping.sh. Add comments to make it reproducible.
We need then to make the file executable.
chmod +x mapping.sh
And execute our bash script.
./mapping.sh
Challenge 11: Have a look at the mapping statistics. What do you think about the mapping rates across the samples (check out _sort.stats and _sort_Q20_nodup.stats)?
Suggestion
| Sample | total | mapped | % | After filtering | % | Coverage |
|---|---|---|---|---|---|---|
| ERR3418932 | 130943 | 122626 | 0.94 | 108009 | 0.83 | 90 |
| ERR3418936 | 126253 | 123034 | 0.97 | 110916 | 0.88 | 90 |
| ERR3418937 | 98889 | 77515 | 0.79 | 67488 | 0.68 | 90 |
| ERR3418961 | 106936 | 4755 | 0.04 | 3525 | 0.03 | 15 |
To get the total number of reads, we are going to use the unfiltered BAM file to avoid mapping more reads than you have in your FASTQ file.
The re-mapping rate of the last sample is rather low. We will take another look at this sample again in the SNP section. Either it is a contaminated sample, or it is from a different strain. Even with a good reference genome, only around 50-70% of the reads are typically retained after filtering for complex genomes like plants.Visualization
If you have identified a gene or region, it is useful to look at the mapping.
First, we need to index the fasta file.
samtools faidx Ref_C_bombi.fasta
Download and install IGV on your own computer use the link here.
Transfer the mappings (bams), the reference (fasta and the Index) and the annotation (gff) file.
Open IGV and import the fasta file under "Genomes" > "Load Genomes from file .." Drag and drop the bam and the gff file.
Challenge 12: How noisy are the mappings? Get a graphical impression. Make some print screens.
